產品介紹
| Fan = AC- FAN | Size = 120x120x38 | Speed = | Flow = | Noise = |
| Bearing type: ◎=Ball ※=Sleeve ●=Hypro Bearing | |||||||||
| Frame Size | Model No | Bearing | Volt. (VAC) | Current (A) | Speed (rpm) | Air Flow (CFM) | Pressure (InAq) | Noise (dB/A) | |
| 120x120x38 | AA1281HB-AWR2T(5E) | ◎ | 115/50 | 0.15~0.19 | 1700~2500 | 88.5 | 0.294 | 43 |  |
| 120x120x38 | AA1281HB-AWR2T(5N) | ◎ | 115/50 | 0.15~0.19 | 1700~2500 | 88.5 | 0.294 | 43 | |
| 120x120x38 | AA1281HB-AWR2T(6E) | ◎ | 115/60 | 0.14~0.19 | 1500~2650 | 95 | 0.200 | 43.6 | |
| 120x120x38 | AA1281HB-AWR2T(6N) | ◎ | 115/60 | 0.14~0.19 | 1500~2650 | 95 | 0.200 | 43.6 | |
| 120x120x38 | AA1282HB-AWR2T(5E) | ◎ | 230/50 | 0.06~0.12 | 1500~2600 | 88.5 | 0.294 | 43 | |
| 120x120x38 | AA1282HB-AWR2T(5N) | ◎ | 230/50 | 0.06~0.12 | 1500~2600 | 88.5 | 0.294 | 43 | |
| 120x120x38 | AA1282HB-AWR2T(6E) | ◎ | 230/60 | 0.07~0.12 | 1450~2800 | 95 | 0.305 | 43.6 | |
| 120x120x38 | AA1282HB-AWR2T(6N) | ◎ | 230/60 | 0.07~0.12 | 1450~2800 | 95 | 0.305 | 43.6 | |
| 120x120x38(at-a1cf) | AA1281HB-AT(A1CF) | ◎※● | 115/50 | 0.27 | 2700 | 91.20 | 0.310 | 42.6 | |
| 120x120x38(at-a1cf) | AA1281HB-AT(A1CF) | ◎※● | 115/60 | 0.22 | 3100 | 103.50 | 0.350 | 47.0 | |
| 120x120x38(at-a1cf) | AA1282HB-AT(A1CF) | ◎※● | 230/50 | 0.13 | 2700 | 91.20 | 0.310 | 42.6 | |
| 120x120x38(at-a1cf) | AA1282HB-AT(A1CF) | ◎※● | 230/60 | 0.11 | 3100 | 103.50 | 0.350 | 47.0 | |
| 120x120x38(at-cf) | AA1281DB-AT(CF) | ◎※● | 115/50 | 0.08 | 2300 | 70.0 | 0.130 | 39.2 | |
| 120x120x38(at-cf) | AA1281UB-AT(CF) | ◎※● | 115/50 | 0.28 | 2400 | 96.00 | 0.240 | 46.4 | |
| 120x120x38(at-cf) | AA1281LB-AT(CF) | ◎※● | 115/50 | 0.12 | 2400 | 76.0 | 0.180 | 40.1 | |
| 120x120x38(at-cf) | AA1281HB-AT(CF) | ◎※● | 115/50 | 0.24 | 2600 | 85.0 | 0.310 | 42.2 | |
| 120x120x38(at-cf) | AA1281MB-AT(CF) | ◎※● | 115/50 | 0.18 | 2600 | 81.5 | 0.240 | 41.0 | |
| 120x120x38(at-cf) | AA1281DB-AT(CF) | ◎※● | 115/60 | 0.08 | 1700 | 53.5 | 0.060 | 30.5 | |
| 120x120x38(at-cf) | AA1281LB-AT(CF) | ◎※● | 115/60 | 0.11 | 2200 | 71.5 | 0.100 | 37.9 | |
| 120x120x38(at-cf) | AA1281UB-AT(CF) | ◎※● | 115/60 | 0.24 | 2600 | 107.00 | 0.250 | 48.1 | |
| 120x120x38(at-cf) | AA1281MB-AT(CF) | ◎※● | 115/60 | 0.15 | 2800 | 87.0 | 0.210 | 42.0 | |
| 120x120x38(at-cf) | AA1281HB-AT(CF) | ◎※● | 115/60 | 0.19 | 2900 | 97.0 | 0.350 | 44.5 | |
| 120x120x38(at-cf) | AA1282DB-AT(CF) | ◎※● | 230/50 | 0.04 | 2300 | 70.0 | 0.130 | 39.2 | |
| 120x120x38(at-cf) | AA1282UB-AT(CF) | ◎※● | 230/50 | 0.14 | 2400 | 96.00 | 0.240 | 46.4 | |
| 120x120x38(at-cf) | AA1282LB-AT(CF) | ◎※● | 230/50 | 0.06 | 2400 | 76.0 | 0.180 | 40.1 | |
| 120x120x38(at-cf) | AA1282HB-AT(CF) | ◎※● | 230/50 | 0.11 | 2600 | 85.0 | 0.310 | 42.2 | |
| 120x120x38(at-cf) | AA1282MB-AT(CF) | ◎※● | 230/50 | 0.08 | 2600 | 81.5 | 0.240 | 41.0 | |
| 120x120x38(at-cf) | AA1282DB-AT(CF) | ◎※● | 230/60 | 0.04 | 1700 | 53.5 | 0.060 | 30.5 | |
| 120x120x38(at-cf) | AA1282LB-AT(CF) | ◎※● | 230/60 | 0.05 | 2200 | 71.5 | 0.100 | 37.9 | |
| 120x120x38(at-cf) | AA1282UB-AT(CF) | ◎※● | 230/60 | 0.12 | 2600 | 107.00 | 0.250 | 48.1 | |
| 120x120x38(at-cf) | AA1282MB-AT(CF) | ◎※● | 230/60 | 0.07 | 2800 | 87.0 | 0.210 | 42.0 | |
| 120x120x38(at-cf) | AA1282HB-AT(CF) | ◎※● | 230/60 | 0.09 | 2900 | 97.0 | 0.350 | 44.5 | |
Note：
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規(guī)電流值；若有進一步需求，請直接與浩禧業(yè)務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
1."Current"欄位所記載的數據僅為實際測量值，并且將有可能不同于安規(guī)電流值；若有進一步需求，請直接與浩禧業(yè)務人員聯絡，謝謝！
2."Model No"欄位內，"＊"符號代表為"preliminary"機種
